VLSI 16-bit ADC with a Sampling Frequency of 200 MHz
- Purpose: Critical application systems, digital signal processing systems, radar, communications, measuring equipment.
- Year of release: 2018
- Guaranteed service life (years): 3
- Estimated production / delivery time (months): 12
- Flight qualification of the product: No
- Possibility to adapt the product to customer requirements: No
| Parameter | Value |
|---|---|
| W*H*T | 26.6*26.6*2.9 mm |
| Weight | 3 g |
| Supply voltage | 2.5±5% V |
| Operating temperature range | -60 - +85 C° |
| Digital Supply Voltage | 1.2В ±5% V |
| Case | Н18.64-2В |
| Consumption current | 0.545 А |
| Capacity | 16 bit |
| Sampling frequency | 200 MHz |
| Differential nonlinearity | -0,9…+1 LSB |
| Integral nonlinearity | ±10 LSB |
| Dynamic range free of interference | 85 dB |
| Signal to noise ratio | 75 dB |
- VLSI of a 16-bit conveyor-type ADC with a sampling frequency of 200 MHz is manufactured using CMOS 90-nm technology and is designed for analog-to-digital conversion of differential analog signals. The chip has an algorithm for the built-in calibration of the transfer characteristic.
