Intersattelite Optical Communication Terminal

    • Intersattelite Optical Communication Terminal

    Purpose:
    Providing communications in the constellation of satellites on LEO for the organization of space Internet and communications, support for network configurations.
    Guaranteed service life (years): 7
    Estimated production / delivery time (months): 12
    Flight qualification of the product: No
    Possibility to adapt the product to customer requirements: Yes
    Submit application


    Parameter Value
    Communication range, km from 500 to 4500
    Data transfer rate, Gbit / s from 10 to 100
    Weight, kg 12
    Viewing angle, degrees in azimuth; in elevation 360; 32
    Average power consumption per revolution, W 60
    Clear aperture 96
    Target tracking speed, degrees / s 5
    The possibility of including in the quantum cryptography channel yes, transmitter
    Power-supply voltage, V 24-36

    Description

    Optical communications equipment for work in the constellation of satellites at the same height. Monoblock design.

    Remark

    Adaptation to any platform with a weight of 300 kg.
