Optical Telecommunication Terminal

    • Optical Telecommunication Terminal

    Purpose:
    Ground segment for the organization of a communication channel with satellites on LEO, including microsatellites.
    Guaranteed service life (years): 25
    Estimated production / delivery time (months): 12
    Flight qualification of the product: No
    Possibility to adapt the product to customer requirements: Yes
    Submit application


    Parameter Value
    Communication range, km (including atmospheric section) not less than 3000
    Data transfer rate, Gbit / s from 0,1 to 10
    Weight, kg 300
    Viewing angle, degrees in azimuth; in elevation 360; 120
    Consumption, W 600
    Clear aperture 155
    Target tracking speed, degrees / s 2
    The possibility of including in the quantum cryptography channel yes, transmitter
    Power-supply voltage, V 24-36

    Description

    Ground contact point with spacecraft at LEO. Mobile design, placement on roofs of buildings and other non-specialized objects is possible.

    Remark

    Mobile and stationary performance, adaptation for any support.
